Huvitz HAB-8000X Auto-Blocker
Effective multi-tasked auto blocking.
Or please call FAISAL: 079 242 2817 or AHMED: 082 414 1472
Description
Click here to view the pdf catalogue
Digital Scan & Hole Detection
It is possible to scan shape and recognize hole by simply placing the lens in the blocking center, the lens is displayed on screen by 1:1 ratio in real-time and size.
Auto Mechanism
- Automatic lens type recognition : single vision, bi-focal, progressive, etc.
- Accurate reading of SPH, CYL, AXIS by integrated high performance lensmeter
- No lens needs to be marked
Specifications
| Tracing Type | Refer to the specification of the frame reader) |
|---|---|
| Tracing Mode | |
| Tracing Size | |
| Frame Material | |
| Frame Data Processing | |
| Measurement | SPH : -10D~+10D, Cyl:±6D (min. step 0.01D) |
| Blocking Tolerance | -0.5~+0.5mm, Axis ±1° |
| Blocking Method | Automatic free location |
| Blocking Pressure | 3.0kgf |
| Lens Recognition Mode | Intelligent, Auto, Manual, Semi-auto (for laser mark) |
| Lens Type Recognition | Single, Bi-focal, Progressive, 3-dot |
| Digital Scan | Shape, Hole/Slot/Notch, Step bevel line |
| Blocking Assistance | Camera zoom, PD/OH live adjustment, Lens shortage check, Block attachment check, Auto brightness control |
| Layout Factors | FPD/DBL, PD (Binocular, Monocular), Cylinder axis, OH (ΔY, Mixed height, Box height), Centering method (Box center, Optical center) |
| Edging Factors | Lens material (Refer to the edger) Edging type (Refer to the edger) Edging position (Refer to the edger) Edging option: Polishing, Safety beveling, Safety mode |
| Functions | Job manager, Digital pattern, Hole editor, Asymmetric bevel editor, Scan & Cut shape editor, Step bevel editor, Image/CAD file converter, OMA import/export, CAD file export, Auto job save & transmission, R/L shape correction, DCS/OMA compatibility |
| Utilities | Tiltable LCD screen SD card storage (Memory card included) Barcode reader interface |
| Display | 10.4”color TFT LCD(1024x768) with touch screen |
| Dimensions / Weight | 300(W) x 470(D) x 560(H)mm / 23kg |
| Power Supply | AC 100-240V 50/60Hz |
| Power Consumption | 75W |
| Designs and details can be changed without prior notice for improvements. | |
